Sumo Logic Scaler

The Sumo Logic scaler allows you to automatically scale applications based on Sumo Logic logs searches, and metrics queries. You can use this scaler to trigger scaling actions based on custom logs or metrics collected in your Sumo Logic account.

You must configure a TriggerAuthentication resource to authenticate with Sumo Logic.

Prerequisites

A Sumo Logic Access ID and Access Key

Authentication Parameters

Authentication is handled through a Kubernetes Secret combined with a TriggerAuthentication.

apiVersion: v1
kind: Secret
metadata:
  name: sumologic-auth-secret
data:
  accessID: <base64-encoded-accessID>
  accessKey: <base64-encoded-accessKey>

---

apiVersion: keda.sh/v1alpha1
kind: TriggerAuthentication
metadata:
  name: keda-trigger-auth-sumologic
spec:
  secretTargetRef:
    - parameter: accessID
      name: sumologic-auth-secret
      key: accessID
    - parameter: accessKey
      name: sumologic-auth-secret
      key: accessKey

Trigger Specifications

Logs Query Trigger

Scale based on a Sumo Logic logs query result.

triggers:
- type: sumologic
  metadata:
    host: "https://api.sumologic.com"   # Sumo Logic API endpoint
    queryType: "logs"                   # Type must be "logs"
    query: "_view=my_view | count"      # Your Sumo Logic logs query
    resultField: "_count"               # Field to extract value from
    timerange: "15m"                    # Lookback window
    timezone: "Asia/Kolkata"            # Timezone (e.g., Asia/Kolkata)
    queryAggregator: "Max"              # Aggregation method: Latest, Avg, Sum, Count, Min, Max
    threshold: "1000"                   # Threshold for scaling
  authenticationRef:
    name: keda-trigger-auth-sumologic

Parameter List:

Name	Description	Required	Example
`host`	Sumo Logic API endpoint URL (Based on your Geo).	Yes	`https://api.sumologic.com`
`queryType`	Type of query.	Yes	`logs`
`query`	Sumo Logic query.	Yes	`_view=my_view \| count`
`resultField`	Field from query results to extract the scaling metric.	Yes (`logs` only)	`_count`
`timerange`	Time range to evaluate the query.	Yes	`15m`
`timezone`	Timezone for query execution.	Optional (`UTC` default)	`Asia/Kolkata`
`queryAggregator`	Aggregation method (`Latest`, `Avg`, `Sum`, `Count`, `Min`, `Max`).	Optional (`Avg` default)	`Max`
`threshold`	Target value for scaling.	Yes	`1000`

Metrics Query Trigger

Scale based on a Sumo Logic metrics query result.

triggers:
- type: sumologic
  metadata:
    host: "https://api.sumologic.com"
    queryType: "metrics"
    query: "metric=cpu.usage | avg"
    quantization: "15s"
    rollup: "Max"
    timerange: "15m"
    timezone: "Asia/Kolkata"
    queryAggregator: "Max"
    threshold: "50"
  authenticationRef:
    name: keda-trigger-auth-sumologic

Additional Fields for Metrics Queries:

(In addition to all common fields from logs queries.)

Name	Description	Required	Example
`quantization`	Granularity of data points.	Yes (`metrics` only)	`15s`
`rollup`	Metrics rollup type (`Avg`, `Sum`, `Min`, `Max`, `Count`).	Optional (`metrics` only, `Avg` default)	`Max`

Multi-Metrics Query Trigger

Scale based on multiple Sumo Logic metrics queries combined together.

triggers:
- type: sumologic
  metadata:
    host: "https://api.sumologic.com"
    queryType: "metrics"
    query.A: "metric=requests_total | rate"
    query.B: "metric=request_capacity"
    query.C: "(#A / #B) * 100 along service"
    resultQueryRowID: "C"          # Which query result to extract
    quantization: "15s"
    rollup: "Max"
    timerange: "15m"
    timezone: "Asia/Kolkata"
    queryAggregator: "Max"
    threshold: "75"
  authenticationRef:
    name: keda-trigger-auth-sumologic

Additional Fields for Multi-Metrics Queries:

Name	Description	Required	Example
`query.A`, `query.B`, `query.C` etc	Multi-stage queries, where later queries can refer to earlier ones.	Yes (for `multi-metrics queries`)	`-`
`resultQueryRowID`	Which final query (`A`, `B`, `C`, etc.) to use for scaling.	Yes (for `multi-metrics queries`)	`C`

Notes

pollingInterval controls how often KEDA polls Sumo Logic.
cooldownPeriod controls how long KEDA waits before scaling down.
MetricType: The scaler supports both AverageValue and Value metric types.
Ensure that the Sumo Logic user has appropriate access to the queries being executed.
